Super ATV 2020-2025 Kawasaki Teryx KRX 1000 6" Portal Gear Lift
Fitment:
- Kawasaki Teryx KRX 1000 : 2020-2025
- Kawasaki Teryx KRX 4 1000 : 2023-2025
Wheel Requirements:
- 18” or larger wheel required
- 18” wheels cannot exceed 4-1/2” backspacing
- 20” and larger wheels cannot exceed 5” backspacing
- Wheels need to have a center hole of at least 3.25" (82.55mm) or require a 1” wheel spacer
Super ATV’s GDP Portal Gear Lifts are built to handle any kind of riding, whether you’re tackling mud, rocks, or trails on your Kawasaki Teryx KRX 1000.
Riders can customize their setup with 30%, 45%, or 60% gear reductions, cast or billet aluminum housings, and single or dual idler gears. The optional dual idlers add extra strength by spreading the load across more surface area for smoother, more reliable torque transfer. With a 6” lift and hub-based gear reduction, these portals boost torque, allow for larger tires, and reduce stress on your drivetrain components.
Built with precision-ground 9310 alloy steel gears, reinforced housings, heavy-duty backing plates, advanced seals, and high-performance bearings, GDP portals are engineered for durability and long-lasting performance. They also feature stainless steel slotted rotors and universal hubs to fit multiple wheel bolt patterns, making them as practical as they are tough.
Designed and tested by experienced riders, these portals deliver strength, protection, and confidence for even the most demanding off-road adventures.
6” Portal Gear Lift Includes:
- (4) Assembled portal hub boxes complete with 9310 gears, seals, output shaft, gaskets, and thrust bearings.
- (4) Universal hubs and precision-ground stainless steel slotted rotors with lugs
- (4) Specialized steel alloy backing plates
- (4) Steel caliper mounting plates with spacers
- (2) Steel steering arms
- Extended brake lines with parking brake and brake cable brackets
- All required hardware, including recessed castle nut socket
Features:
- Available with billet or cast aluminum housings
- Dual idler gear configuration maximizes strength
- Cool, quiet, precision ground gears made from 9310 alloy billet steel
- 1.5 in. diameter 4340 hardened steel drive shaft
- Housings use advanced gaskets that don’t let anything through
- Universal hub fits all major bolt patterns
- Gear reduction reduces stress on your drivetrain
- Dual idler gear configuration adds a 1” front and rear offset - 2” total extension
- Lighter than the competition total, which is 25+ lb. lighter than the competition
