DS18 Audio Can-Am Maverick X3 Dashboard Panel Loaded w/ 6.5" Speaker & Digital Lights
DS18"s CA-X3DS6LDV2 Can-Am Maverick X3 Dashboard Panel Loaded w/ 6.5" Speaker & Digital Lights brings serious sound and style to your CAN-AM X3 (2017"2023). This complete dash upgrade comes loaded with dual 6.5-inch DS18 NXL-IQ6/BK coaxial speakers that are IP65-rated for water and dust resistance. Each speaker delivers 150W RMS and 300W peak power at 4 ohms, giving you crisp highs and punchy bass that cut through any terrain. The open baffle design improves projection, while the digital LED lighting built into each pod transforms your ride with a custom glow.
Designed for plug-and-play fitment, these panels bolt directly into factory dash locations without cutting or modifications. Made from durable, UV-resistant polyethylene with a black textured finish, they blend seamlessly with your OEM styling. Pair the lighting with DS18"s LC-DRM controller (sold separately) for full app control, and follow the included Smart-Lok relocation instructions if your X3 is equipped. With powerful sound, rugged build, and integrated LEDs, the CA-X3DS6LDV2 is the ultimate CAN-AM X3 dash audio upgrade.
Features
- Panels Sold as a Set for Driver and Passenger Sides
- Includes One Set of 6.5" NXL-IQ6/BK Waterproof Speakers With Digital LED
- OFC Wiring, Tinned for More Power Handling and Durability
- 5 Core 0.6M Input Wires for Speaker and Digital LED Lighting
- Black Texture Finishes Like OEM Plastics
- Durable (PE) Waterproof Panels With UV Protection
- Open Baffle Speaker Panel Design
Includes
- (1) Left & Right Speaker Panels
- (2) NXL-IQ6/BK Speakers
- Speaker and Digital LED Light Wire Harness
Specifications
General
-
Total Watts (Peak): 300W
-
Total Watts (RMS): 150W
-
Total Impedance: 4+4 Ohms (Left & Right Channels)
-
Sensitivity (1w/1m): 95dB
-
Frequency Response: 45Hz - 20kHz
-
Recommended High Pass Crossover: 60Hz
Enclosure
-
Box Type: Front Baffle
-
Box Material: Polyethylene (PE)
-
Finish Material: Black
-
UV Protection: Yes
-
Waterproof Rating: IP65
-
Input Wire (Harness): 2 x 6 Core OFC Tinned (2ft / 0.6m)
Woofer
-
Speaker Type: 6.5" Waterproof Coaxial with Digital LED
-
Voice Coil Diameter: 1.5" / 38.6mm
-
Voice Coil Former Material: Glass Fiber
-
Winding Material: CCAW
-
Cone Material: UV-Compliant Injection Molded Polypropylene
-
Surround Material: Butyl (Rubber)
-
Basket Material: Injection Molded Composite PC with UV Coating
-
Magnet Material: Ferrite + Neodymium
-
Magnet Weight: 13 oz + 1.1 oz
Tweeter
-
Type: Floating Bullet Tweeter
-
Voice Coil Diameter: 1" / 25.4mm
-
Voice Coil Former Material: Kapton
-
Winding Material: CCAW
-
Diaphragm Material: Aluminum
-
Bullet Material: Injection Molded Composite PC with UV Coating
-
Magnet Material: Neodymium (N35H)
-
Magnet Weight: 0.4 oz
Driver Side Enclosure
-
Height: 5.86" / 149mm
-
Width: 20" / 506mm
-
Depth: 20.4" / 520mm
Passenger Side Enclosure
-
Height: 6.1" / 155mm
-
Width: 20" / 518mm
-
Depth: 19.3" / 490mm
-
Speaker Mounting Hole Diameter: 5.7" / 145mm
Fitment
-
OEM 2017-2023 Can-Am Maverick X3
